Features

• 30″ wide TOP SHOT side discharge expeller beater
• 24″ diameter round core segmented auger
• The 540 RPM PTO driven system features a sprocket reduction system with heavy-duty chain and an overrunning torque limiting clutch for protection and smooth power transfer.
• A master/slave cylinder system raises and lowers the main auger evenly to keep material moving to the expeller.
• The auger system hydraulically raise and lower a full 8″ to break-up material that may bridge during the unloading process.
• Reversible bolt-on square tooth paddles shred and rip material with a TOP SHOT action for an even spread pattern.
• The heavy-duty expeller system, with a quick release poly-lined fine spread pan and side fins, helps cut the drift of material towards the tractor and spreader and provides an excellent spread pattern.
• A manual adjust top expeller shield allows you to set the distance of material being discharged.
• The left side tank poly liner allows material to slide to the auger.
• Adjustable hitch
• Shear bolt protection
• Remote grease system
